14. CAS & Command Mode Protocol
CAS Protocol (22 bytes) – ASCII Code
ⓐ ⓑ
,
ⓒ ⓓ
,
ⓔ ⓕ
,
Weight Data (8byte)
ⓖ ⓗ ⓘ ⓙ ⓚ
ⓐ ⓑ ST (Stable), US (Unstable), OL (Over Load)
ⓑⓓ GS (Gross), NT (Net) ⓔ Device ID
ⓕ
Lamp condition ⓖ Blank
ⓗ
k
ⓘ
g
ⓙ
CR
ⓚ
LF
Note. 1 Device No. is the successive value of ASCII code.
Ex) Device No. 01 : 0x31, Device No. 09 : 0x39, Device No. 13 : 0x3d
Limit Protocol (22 bytes)
ⓐ ⓑ ⓒ ⓓ ⓔ ⓕ ⓖ
Weight Data (8byte)
ⓗ ⓘ ⓙ ⓚ ⓛ ⓜ ⓝ
ⓐ ⓑ ST (Stable), US (Unstable), OL (Over Load)
ⓑⓓ GS (Gross), NT (Net) ⓔ Device ID
ⓕ
Lamp condition ⓖ Code (ASCII)
ⓗ
Blank
ⓘ
Zero signal
ⓙ
Low limit
ⓚ
High limit
ⓛ
OK signal
ⓜ
CR
ⓝ
LF
Note. 1 The Zero signal is on within 10 division.
Note. 2 When the signal of Zero(ⓘ) ~ OK(ⓛ) is on, the data is 0x31,
When the signal of Zero(ⓘ) ~ OK(ⓛ) is off, the data is 0x30.
