CAS NT-580A - Page 33

3
4
Serial Interface of COM1 Function
F28
Function Set Baud Rate of COM1
VFD Display DESCRIPTION
F28 0 600 bps
F28 1 1200 bps
F28 2 2400 bps
F28 3 4800 bps
F28 4
9600 bps
F28 5 19200 bps
F28 6 38400 bps
F28 7 57600 bps
Set Value
(0 ~ 8)
F28 8 115200 bps
F29
Function Usage of COM1
VFD Display DESCRIPTION
F29 0
Connection with printer
Set Value
(0 ~ 1)
F29 1 Connection with sub-display or computer
* F29 =0 and F33 = 0 then “Err-Set” displayed. and the print is disconnected.
F30
Function Output Format of COM1
VFD Display DESCRIPTION
F30 0
22Bytes – CAS Format
F30 1 10Bytes – CAS Format
Set Value
(0 ~ 2)
F30 2 18Bytes – AND Format
F31
Function Output Mode of COM1
VFD Display DESCRIPTION
F31 0
No data transmission
F31 1 Transmit data in a state of stable & unstable (Stream Mode)
F31 2
Transmit data only in stable condition
(Transmit 1 time after load in stable condition)
F31 3
Transmit data if you input Device ID
* Device ID (F31) Input 1Byte (hex code)
(Data Request _Device ID : 1= 0x01, 10 = 0x0A)
Set Value
(0 ~ 4)
F31 4 Transmit data only in command Mode
* If it is used as the print Mode, set F31 = 1.
