9-5. Analog Out Interface(0~10V)
▣Set F66=2
▣Specification
Output voltage 0 - 10V
Resolution More than1/1000
Temperature Coefficient 0.01%/℃
▣The output voltage is 0V when the display weight is “0”.
And the output voltage is 10V when the display weight is the maximum capacity.
▣Minute adjustment of Output current
(1)The output voltage is 0V in a factory shipment when the display weight is “0
And the output voltage is 10V in a factory shipment when the display weight is the maximum
capacity.
(2)Adjust VR
1
(zero), VR
2
(span) of the option PCB in the indicator if the output current is not
correct.
Analog Out PCB ▣ S/W Setting
(1) Model Selection (SW3)
SW3
NT-500
NT-570
NT-500 Select
(2) Voltage output range setting(SW1, SW2)
SW1 SW
2
1
0
0 - 10V
