CAS NT-580A - Current Loop Serial out

73
9. Option
9-1. Current Loop Serial Out
▣ Transmit Mode : Same as RS-232C
F27 Baud Rate 600, 1200, 2400bps
F30 Output Mode Stable, Unstable, Data is required
▣ Signal Format : Same as RS-232C
1
20 mA
0
0 mA
▣ Data Format : Same as RS-232C
Current Loop ▣ Pin Connection (25pin D-type male port)
Pin No Signal
9 Current Loop Output
7 Ground
11 Current Loop Output
18 Ground
25 Current Loop Input
