6-3. Test Menu
Test 1 : Key Test
Test 2 : Display Test
Test 3 : A/D(Loadcell) Test
Test 4 : Serial(RS-232) Test (COM1, COM2)
Test 5 : Print Test
Test 6 : External Input / Output Test
Test 7 : BCD Out Test (Option – 3)
Test 8 : Analog Out Test (Option – 4,5)
Test 9 : BCD In Test (Input Set Point)
Test 10 : RTC(Real Time Clock) Test
Test 1
Function : Key Test
Use Key DISPLAY DESCRIPTION
ENTER : Select menu
Shift Mode
TEST 1
It means the Test Mode 1
Other key : Perform Test
1 1
Press any key to Test then the display
show its number and code.
Ref 1. Execute the Test 6 for the external input/output Test.
Ref 2. Key list
KEY
ZERO TARE KEY TARE
GROSS/NET *
ENTER
CODE
60 61 62 63 18 15
Test 2
Function : Display Test
Use Key DISPLAY DESCRIPTION
TEST 2
It means the Test Mode 2
*, ENTER : Select menu
Shift Mode
8888888
All on display segment
