3-CONTROLSANDINSTRUMENTS

Coathangerhook

Thehook(1)ttedontheleft-handcabupright,allowsthe

hangingofpossibleclothes.

LEEN11T0073AA12

Airlter

NOTE:Yourairlterassemblymayappearslightlydiffer-

entfromtheoneshownbuttheairlterlocationisthe

same.

Theairlterislocatedundertheoperator’sseat.

See7-44forthemaintenanceprocedure.

LEEN11T0074AA13

Fireextinguisher

DANGER

Firehazard!

Alwayshaveareextinguisheronornear

themachine.Keepthereextinguisherin

goodconditionthroughroutinemaintenance

andserviceaccordingtothemanufacturer's

instructions.

Failuretocomplywillresultindeathorserious

injury.

D0006A

Thereextinguisher(1)islocatedtotherightofthesteer-

ingwheel.

Ontakingdeliveryofthemachine,studythereextin-

guisheroperatinginstructions.

Theinstructionsareprintedontheextinguisher.

LEEN11T0077AA14

3-46
