1-GENERALINFORMATION

Productidentication

Whenorderingparts,requestinginformationorassistance,alwaysgiveyourDealerthemodelandProductIdenti-

cationNumber(PIN)ofyourmachineandcomponentconcerned.

Machine

Model:

PIN:

RAIL15TLB0177BA1

580Tand580STengine

FiatPowertrainTechnologies(FPT)72kW(98Hp)

F4GE9484C(580T)orF4HE0484G(580ST).

PIN:

LEEN11T0339AA2

1-6
