(3)Gearshiftlever(onlyonPowershiftmodels)
Thissignindicatestoreadtheoperator’smanualto
understandtheoperationofthegearshiftlever.
Location:
Sitintheoperator’sseat,facetheloaderarmanditison
theleft-handsideofthesteeringwheel.
Quantity:1
Partnumber:
84148447
LEEN11T0436AA24
(4)Transportheight
Alwaysremembertotaketheheightofthebackhoeboom
intoconsiderationwhentravelingwithortransporting
themachineonatrailer.Themaximumheightfromthe
groundisapproximatelyidentiedonthesafetysign
ofyourmachine.Whentransportingthemachine,be
suretoknowthedistancebetweenthegroundandthe
highestpointofthemachine.
NOTE:Thissafetysignisspecictocertaincountries.
Location:
Cablocation:
Sitintheoperator’sseat,facetheloaderarmanditison
theupperright-handsideofthefrontwindow.
Canopylocation:
Sitintheoperator’sseat,facetheloaderarmanditison
theinsideupperright-handsideoftheROPS.
Quantity:1
Partnumber:
(A)47896667(580Tand580STwithin-linecylinder
boom)
(B)84378622(580T,580ST,590STwithoverlapping
cylinderboom)
(C)84328628(695ST)
(A)
4789666725
(B)
8437862226
(C)
8437862827
