3-CONTROLSANDINSTRUMENTS
•
Presstheswitchontheuppersideofthesymbol
toshiftthebackhoeattachmenttotheright
sideofthetrack.
•
Presstheswitchonthelowersideofthesymbol
toshiftthebackhoeattachmenttotheleftside
ofthetrack(tracksidesarereferredtothetravel
directionofthemachine).
10.Hornswitch:(onlymodelswithmechanicalbackhoe
controls):
•
Thisswitchoperatesthewarninghorn.
11.Backhoeattachmentsideshiftcarriagelocking
switch(Sideshiftversion)
•
Itallowslocking(controllampon)orunlocking
(controllampoff)theslidingcarriagethebackhoe
attachmentismountedon.
