— 38 —
9. Put the upper and lower case as shown figure. And disconnect
the backup battery, speaker and button PCB cable.
10. Remove main PCB and LCD module from upper case as shown
figure.
11. Remove LCD module from main PCB as shown figure.
12. Disconnect FPC and LCD cable as shown figure.
Disconnect
Disconnect
Unscrew
1
2
