2.4 LED
There are two LEDs, a charge complete LED (the left side) and an LED for user notice (the right
side).These can be turned on and off individually.
The functions of each are as follows:
(1) Charge completion LED (the left side)
This is for recharge status, notifying that power is being supplied for charging (it cannot be lit by user
instructions).
(2) LED for user notice (the right side)
i This LED lights or flashes for scan complete, alarm occurrence, warning occurrence, wireless
incoming call, and user-specified purpose.
It is used for user notifications, for completion of scanning by the scanner, for wireless
connection status (Bluetooth, wireless LAN,), and for user-specified purposes.
ii LED lighting can be suppressed from the system library.
For details, refer to the System Library Manual.
The LED state
Color Purpose
Orange Recharging
Green Recharging complete
LED１
(Recharge)
Red Recharge error
Red User notification (alarm), scanning error
Green Scanning successful
Blue Connection established via Bluetooth
Orange wireless LAN connected
Magenta In USB connection (ActiveSync, FLCE, WMDC, LMWIN, etc.)
LED2
(General
purpose)
Cyan Resuming
All colors can be used by user specification.
