The following four types of symbols are compatible with the sign clipping function.
Supported symbols Remarks
Code39
Code128
PDF417
Aztec Code
(3) Streaming display
This function runs the scanner continuously to continuously display the image. When used together
with “2.12.1 Imaging Capture”, it can be used as a camera viewfinder.
Function Image size
Reduction (downsampling)
specification
x1/1, x1/2, x1/4
When x1/1 is
specified
832×640 pixels
When x1/2 is
specified
416×320 pixels
When x1/4 is
specified
208×160 pixels
When x1/5 is
specified
-
Image size
Free clipping Possible
Gradations 256-level grayscale
Frame rate 15fps or less (*1)
(*1) The frame rate may vary due to brightness of the surroundings and the impact of system loads
(due to running programs etc.)
