Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 40 –
M-type Drawer
18: SE-S100MA_BK
19: SE-S100MA_GD
20: SE-S100MA_RD
21: SE-S100MB_BK
22: SE-S100MD_BK
23: SE-S100MD_GD
24: SE-S100MD_RD
25: SE-S100MD_SR
26: SE-S100MG_BK
27: SE-S100MG_GD
28: SE-S100MK_BK
29: SE-S100MK_GD
18 19 20 21 22 23 24 25 26 27 28 29
FINAL-ASSY
N 1 10500428 COVER/PRINTER/GD RJE504003-006V01 1 1 1 1 C
N 1 10500427 COVER/PRINTER/SR RJE504003-005V01 1 C
N 1 10500426 COVER/PRINTER/RD RJE504003-004V01 1 1 C
N 1 10500425 COVER/PRINTER/BK RJE504003-003V01 1 1 1 1 1 C
2 10349665 PULLY/WIND RJE501880-001V04 111111111111C
3 10445632 SPOOL/PAPER RJE504072-001V01 111111111111C
4 10445436 COVER/BATTERY RJE504019-001V01 111111111111C
N 5 10254924 SUB ASSY/KEY SET RJE500074*002V03 111111111111C
N 6 10500440 COVER/SD RJE504387-001V01 111111111111C
N 7 10271807 HOLD/ROM RJE502216-001V01 111111111111C
N 11 10500434 COVER/TOP RJE504381-001V01 111111111111C
12 10230087 PLATE RJE500775-001V02 222222222222X
13 10445438 COVER/CORD RJE504014-001V01 111111111111C
N 14 10500435 COVER/PCB RJE504382-001V01 111111111111C
14-1 Cloth tape/25x50 25WX50L 3 33333333333X
14-2 Copper foil tape/20x40 20WX40L 222222222222X
15 10331637 SUBASSY/TRAY RJE503185*001V01 111111111111X
S3 Screw (3x8) S-BDPT-3X8Z3 444444444444X
S4 Screw (3x8) S-BDST-3X8Z3 111111111111X
Q'T
Y
RN Item Code No. Parts Name Specification

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
