SE-S100 / PCR-T285 / PCR-T295
– 41 –
M-type Drawer
18: SE-S100MA_BK
19: SE-S100MA_GD
20: SE-S100MA_RD
21: SE-S100MB_BK
22: SE-S100MD_BK
23: SE-S100MD_GD
24: SE-S100MD_RD
25: SE-S100MD_SR
26: SE-S100MG_BK
27: SE-S100MG_GD
28: SE-S100MK_BK
29: SE-S100MK_GD
18 19 20 21 22 23 24 25 26 27 28 29
Q'T
Y
RN Item Code No. Parts Name Specification
U-CASE-ASSY
N 16 10508649 CASE ASSY/UPPER TK-RJE504496*010 1 1 1 1 1 C
N 16 10508648 CASE ASSY/UPPER TK-RJE504496*009 1 1 1 1 C
N 16 10508647 CASE ASSY/UPPER TK-RJE504496*008 1 1 C
N 16 10508646 CASE ASSY/UPPER TK-RJE504496*007 1 C
17 10294939 SPRING/BATTERY/B-2E RJE502620-001V01 1 1 1111111111C
18 63452238 SPRING/BATTERY/G55 A42606B-1 1 1 1111111111C
19 10294940 SPRING/BATTERY/G67E RJE502622-001V01 1 1 1111111111C
20 10350060 CABLE/SUBASSY/BATTERY RJE503227*001V02 1 1 1111111111C
21 10445426 ROLLER/D-P RJE504041-001V01 2 2 2222222222C
22 10236317 CUTTER/PAPER E441364-001V02 1 1 1111111111C
23 10503749 SHEET/BATTERY RJE504492-001V01 1 1 1111111111X
24 10445805 PLATEN ARM RJE504004-001V01 1 1 1111111111C
25 10451728 MOTOR TK-E441295*003 1 1 1111111111A
26 10334571 MODE KEY TK-E341249*004V01 1 1 1111111111C
27 10501928 PRINTER FTP628MCL518#70-R 1 1 1111111111A
28 10262839 STOPPER RJE502189-001V01 1 1 1111111111X
29 10500432 MOUNT/PRINTER RJE504378-001V01 1 1 1111111111C
30 10500433 MOUNT/PCB RJE504379-001V01 1 1 1111111111C
31 10497745 HOLDER/IC RJE504404-001V01 1 1 1111111111C
32 10500423 CABLE/FFC/JOINER E441341-020V04 1 1 1111111111C
33 10507407 PCB ASSY/E286-1 TK-RJE504414*001V01 1 1 1111111111A
FU1 10225980 FUSE (600mA) 230.600MXP 1 1 1111111111A
S3 Screw (3x8) S-BDPT-3X8Z3 101010101010101010101010 X
S5 Screw (3x6, washer) S-PASEMA-3X6Z3 5 5 5555555555X
S6 Screw (2x5) S-BDST-2X5Z3 222222222222X
S7 Screw (3x5) S-BDST-3X5ZC 444444444444X
S8 Screw (3x14) S-BDPT-3X14Z3 222222222222X
S9 Screw (3x8) S-BDST-3X8ZC 111111111111X
