Casio SE-S100 Service Manual

SE-S100 / PCR-T285 / PCR-T295
– 42 –
M-type Drawer
18: SE-S100MA_BK
19: SE-S100MA_GD
20: SE-S100MA_RD
21: SE-S100MB_BK
22: SE-S100MD_BK
23: SE-S100MD_GD
24: SE-S100MD_RD
25: SE-S100MD_SR
26: SE-S100MG_BK
27: SE-S100MG_GD
28: SE-S100MK_BK
29: SE-S100MK_GD
18 19 20 21 22 23 24 25 26 27 28 29
Q'T
Y
RN Item Code No. Parts Name Specification
PS-ASSY
34 10500439 MOUNT/PS-UNIT RJE504386-001V01 111111111111C
34-1 Cloth tape/19x50 W19XL50 111111111111X
34-2 Cloth tape/19x20 W19XL20 111111111111X
35 10500403 PS-UNIT EGF0800300Y1BA 111111111111A
36 10240097 CORD/POWER AR1CSEX270-SAA-ALF 1 1 1 C
36 10240096 CORD/POWER AR1CSEX270-UKLF 1 1 1 1 1 1 C
36 10366973 CORD/POWER LG276EU 1 1 1 C
37 10507408 DISPLAY-UNIT TK-RJE504417*001V01 111111111111A
38 10500462 SHEET/SHIELD/LCD RJE504424-001V01 111111111111X
38-1 D-TAPE/SHEET W5XL5 222222222222X
39 10445424 FRAME/DISPLAY RJE504043-001V01 111111111111C
KEY-BOARD-ASSY
40 10501113 FLAME/KEY BOARD RJE504364-001V01 111111111111C
41 10501117 CHASSIS/KEY BOARD RJE504365-001V01 111111111111X
42 10501114 FPC RJE504361-001V01 111111111111B
43 10501116 SPACER RJE504363-001V01 111111111111C
44 10501115 SHEET/COMMON RJE504362-001V01 111111111111B
45 10193646 SPRING/PRESS/B E441298-002V03 555555555555C
46 10193645 SPRING/PRESS/A E441298-001V03 222222222222C
47 10501892 KEY TOP/S RJE504470-001V01 36 36 36 36 36 36 36 36 36 36 36 36 C
48 10501893 KEY TOP/L RJE504471-001V01 222222222222C
49 10501894 CAP/S RJE504472-001V01 36 36 36 36 36 36 36 36 36 36 36 36 A
50 10501895 CAP/L RJE504473-001V01 222222222222A
51 10167457 RUBBER/CONTACT RJE501209-002V01 38 38 38 38 38 38 38 38 38 38 38 38 B
S3 Screw (3x8) S-BDPT-3X8Z3 111111111111X
S10 Screw (3x8) S-WLPT-3X8ZC 111111111111X

Casio SE-S100 Specifications

General

Types of payment	Cash
Number of clerks/departments	24
Number of Price Look-Up codes (PLUs)	2000 PLUs
Power source	AC
AC input voltage	100-240 V
Supported paper width	58 mm
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Backlight	Yes
Display digits	10 digits
Second display type	LCD
Display number of lines	2 lines
Display number of characters	20

Weight and Dimensions

Depth	345 mm
Width	326 mm
Height	167 mm
Weight	3300 g
