Casio V-R200

V-R200 Installation Manual
– 2 –
2. Installation Space
To ensure the operability of the product, secure installation space as shown below. Do not place any objects
within the installation space indicated by the dotted rectangle (within 50 mm from the product).
50 mm 50 mm
50 mm
50 mm
Fig. 2
3. Dimensions of the product
395 mm 237 mm
229 mm
Fig. 3
