V-R200 Installation Manual
– 6 –
3. Installing the pop tray
(1) Tilt the product, and attach and slide the pop tray so that the four stoppers on the bottom fi t into the round
holes in the pop tray slide mechanism.
Fig. 7
Stopper
Round holes
Pop tray
(2) Slide the pop tray in the direction of the arrow, and pull it out to the position to be used.
Fig. 8
Do not use the pop tray so as to protrude from the surface where the product is installed. Doing so may
result in damage.
4. Inserting an SD/SDHC memory card
(1) Put your fi nger into the slot on the side and remove the side cover.
Fig. 9
Slot
Side cover
To Next Page
