Casio V-R200

V-R200 Installation Manual
– 10 –
6. Adjusting the angle of the main display
(1) Plug in the AC adaptor to the outlet and turn the power switch ON.
Fig. 19
Power switch
(2) Adjust the angle of the main display to a position that suits the operator’s work by pressing the tilt switch.
Fig. 20
TILT
DOWN UP
TILT
DOWN UP
(3) Attach the tilt switch cover to secure the angle of the main display.
Fig. 21
