V-R200 Installation Manual
– 16 –
2. DRAWER (M-type)
(1) Make sure that the following parts are included in the package.
Drawer
Keys Drawer fi xing hook *1 Drawer fi xing sheet *1
*1: The drawer fi xing hook is for M-size drawer only.
(2) Connect the drawer connecting cable to the drawer.
Fig. 35
NOTE: Connect the longer side drawer connecting cable.
(Cable length: About 85 cm)
NOTE: For the drawer with an earth terminal, connect the earth terminal of
the drawer connecting cable.
To Next Page
