10
Item Description
there is no Ethernet connection.
3
USB USB host port for print server or network storage function
4
RESET Press and hold the RESET button for five seconds or longer to
restore CH6643E to factory default settings. After factory
default settings are restored, the gateway will restart and
may take 5 to 30 minutes to find and lock on the appropriate
communication channels.
5
CABLE Connect the CH6643E to a cable wall outlet.
6
POWER
SWITCH
Switch gear for power on/off the CH6643E.
7
POWER Provide power to the CH6643E.
MAC Label
The CH6643E Media Access Control (MAC) label is located on the bottom of the
CH6643E. The label contains the MAC address which is a unique, 48-bit value that
identifies each Ethernet network device. To receive data service, you will need to
provide the MAC address marked HFC MAC ID to your Internet Service provider.”
