19
3.Basic Configuration
For normal operation, you do not need to change most default settings. Carefully
consider the following caution statements:
Starting the CH6643E Configuration Manager (CMGR)
The CH6643E Configuration Manager (CMGR) allows you to change and view the
settings on your CH6643E.
1.
Open the web browser on a computer connected to the CH6643E over an
Ethernet connection.
Note: Do not attempt to configure the CH6643E over a
wireless connection.
2.
In the Address or Location field of your browser, type
http://192.168.0.1
and
press
ENTER,
and then you will get into homesection.
CMGR provide more information and gateway functions for experienced users in
privileged mode, you can login by click the “LOGIN” button on the top of
window then input Username and Password.
