6
Sample Wireless Network Connections (CH6643E model shown)
Your maximum wireless operation distance depends on the type of materials
through which the signal must pass and the location of your CH6643E and clients
(stations). CBN cannot guarantee wireless operation for all supported distances in
all environments.
Note: To get better wireless coverage, please put your
CH6643E wireless gateway vertically.
Wired Ethernet LAN
You can easily connect any PC with an Ethernet cable to the CH6643E Ethernet
port. Because the CH6643E Ethernet port supports auto-MDIX, you can use a
straight-through or cross-over cable to connect a hub, switch, or computer. Use
category 5, or better, cabling for all Ethernet connections.
