FI002K0021v1100UK – THS/21E and THS/21 Programming Manual
3
CONTENTS
1 SAFETY INSTRUCTIONS – WARNINGS ....... 5
1.1 General warnings ...................................... 5
1.2 Correct use of the device .......................... 5
2 PROGRAMMING ............................................. 6
2.1 Access to Programming ............................ 6
2.1.1 Factory preset configuration ....................... 6
2.1.1.1 Access levels ..................................... 6
2.1.1.2 Remote Communication ..................... 7
2.2 Administrator functions ............................. 7
2.3 Configuration of the system by the
Administrator ............................................. 7
2.3.1 Programming .............................................. 7
2.3.2 Users .......................................................... 7
2.4 General points on programming ............... 8
2.4.1 Keypad functions ........................................ 8
2.4.2 Entering the username ............................... 9
2.4.3 Entering the password .............................. 10
2.4.4 Restricted login ......................................... 10
2.5 Exit from programming ........................... 11
2.5.1 Exit from programming ............................. 11
2.5.2 Time out ................................................... 11
2.6 Defining a new user ................................ 11
2.7 Quick Access menu programming
procedure ................................................ 12
2.8 Programming the Metal Detector
according to the kind of product .............. 13
2.8.1 Procedure for minimizing the "product
effect" ....................................................... 13
2.8.2 Procedure for automatic product
acquisition ................................................ 13
3 PROGRAMMING PARAMETERS ................. 15
3.1 Administrator .......................................... 15
3.1.1 Remote passwords .................................. 16
3.2 Reset ...................................................... 17
3.3 Product selection .................................... 17
3.4 Products .................................................. 18
3.4.1 Save prod.to USB .................................... 20
3.4.2 Load prd. from USB ................................. 22
3.5 Autolearn ................................................ 24
3.6 Autolearn-advanc ................................... 25
3.7 Detection ................................................. 26
3.8 Ejection ................................................... 28
3.9 Counters ................................................. 32
3.10 Configuration .......................................... 33
3.10.1 Compatibility chk ...................................... 33
3.11 Configuration-adv ................................... 37
3.11.1 Network config. ........................................ 40
3.11.2 Motor config ............................................. 50
3.12 Barcode reader ....................................... 53
3.13 I/O Status ................................................ 55
3.13.1 Outputs .................................................... 55
3.13.2 Inputs ....................................................... 55
3.13.3 Measures ................................................. 56
3.13.4 Variables .................................................. 56
3.14 Diagnosis managem. .............................. 57
3.15 MD Test .................................................. 63
3.16 Fail-safe test ........................................... 63
3.17 Print ........................................................ 64
3.17.1 With no IXC card installed ........................ 64
3.17.2 With IXC card installed ............................. 65
3.17.2.1 Save events ..................................... 66
3.18 Q-C setup (Quality Control) .................... 68
3.19 Test samples .......................................... 70
3.20 Unlock bin ............................................... 70
3.21 Commands accessible only in Remote
Programming .......................................... 71
3.22 Remote programming ............................. 76
3.22.1 Communication parameter settings ......... 76
3.22.1.1 RS232 or RS232 Aux ...................... 76
3.22.1.2 Bluetooth ......................................... 76
3.22.1.3 Ethernet / WiFi connections (only
with IXC card) .................................. 76
3.22.2 Entering remote programming ................. 77
3.22.2.1 Connecting to a Metal Detector ....... 77
3.22.2.2 Displaying a parameter setting ........ 77
3.22.2.3 Changing a parameter setting ......... 77
3.22.2.4 Executing a function ........................ 77
