Code Meaning Symptom Solution Saved
EXTERNAL ENTRAPMENT PROTECTION
70
CLOSE EYE/INTERRUPT triggered
on the main board
During the close cycle the gate will
stop and reverse to the full open
position and the Timer-to-Close
becomes disengaged. The gate will
not close.
Check for an obstruction in the path of the gate.
If an obstruction did NOT occur, check the
inputs and wiring on the main control board.
NO
71
CLOSE EDGE triggered on the
main board
During the close cycle the gate will
stop and reverse to the full open
position and the Timer-to-Close
becomes disengaged. The gate will
not close.
72
OPEN EYE/EDGE triggered on the
main board
During the open cycle the gate will
reverse for 4 seconds, then stop. The
gate will not open.
73
CLOSE EYE/INTERRUPT triggered
on the expansion board
During the close cycle the gate will
stop and reverse to the full open
position and the Timer-to-Close
becomes disengaged. The gate will
not close.
Check for an obstruction in the path of the gate.
If an obstruction did NOT occur, check inputs
and wiring on the expansion board.
NO
74
CLOSE EYE/EDGE triggered on
the expansion board
During the close cycle the gate will
stop and reverse to the full open
position and the Timer-to-Close
becomes disengaged. The gate will
not close.
75
OPEN EYE/EDGE triggered on the
expansion board
During the open cycle the gate will
reverse for 4 seconds, then stop. The
gate will not open.
80
Close input (EYE/EDGE)
communication error between
primary and secondary operators
The gate will not move except with
constant pressure.
Check inputs and communication method
between operators, either wired or wireless.
Ensure both operators have power. Erase the
wireless communication and reprogram the two
operators.
YES
81
Open input (EYE/EDGE)
communication error between
primary and secondary operators
82
Close input (EYE/EDGE)
communication error between
main control board and expansion
board
The expansion board LEDs are off
and the gate will not move.
Check the connections between the main board
and the expansion board.
YES
83
Open input (EYE/EDGE)
communication error between
main control board and expansion
board
DIAGNOSTIC CODES
Some codes are saved in the code history and some are not. If a code is not saved it will briefly appear on the display as it occurs, then disappear.
When servicing of the operator is complete, erase the code history by pressing the STOP button until the display flashes “Er” then “CL” (about 6
seconds). When the codes have been erased the display will show “_ _”.
