Chamberlain SL595U - Ac Motors

8
BASIC TROUBLESHOOTING
To protect against fire and electrocution:
• DISCONNECT power (AC or solar and battery) BEFORE installing or servicing operator.
AC MOTORS
SYMPTOM: The motor will not run.
CHECK THE MOTOR:
Disconnect ALL power from operator. Disconnect the gate from the operator. Unplug the motor harness from the board and measure the resistance of
the motor. Refer to illustrations.
SOLUTION: If the motor measured too much resistance or zero resistance, replace the motor.
12
11
10
9
8
7
6
5
4
3
2
1
Blue
Yellow
Yellow/Black
Orange
White
Red
Purple
Yellow/Black
Purple
Black
1
3
10
12
2
456
789
11
Gray
Gray
THERMAL SWITCH
RUN 1
RUN 2
START
RUN 1 = 600 ohms or less
RUN 2 = 600 ohms or less
START = 50k ohms or greater
THERMAL SWITCH = 0 ohms
Measure resistance between:
Unplug motor harness
from power board
BEFORE measuring.
12
13
14
15
11
10
9
8
7
6
5
4
3
2
1
Blue
Yellow
Yellow/Black
Orange
Brown
Gray
White
Red
Purple
Purple
Yellow/Black
Purple
Purple
Purple
Black
1
3
15 13
2
4
56
789
10
11
14
12
Resistance should be
600 ohms or less
15 to 7
14 to 8
12 to 6
11 to 6
9 to 5
Measure resistance between:
Unplug motor harness
from power board
BEFORE measuring.
THERMAL SWITCH
There should be continuity
between 1 and 4 (Thermal Switch)
MODELS CSW200U & SL3000
MOTOR
ID
J14
MOTOR RED MOTOR BLUE
J11
J7 SWITCH
TRANSFORMER
J5
J3
COMM
120VAC
MOTOR
WHITE
J2
J1
INPUT
NEUTRAL
OUTLET
J12
J6
BLACK
WHITE
INPUT
HOT
J4
J10
MOTOR
CONTROL
CURRENT
SENSOR
J8
J16
SWITCH
J17 J20
J13
J19 J21
J18
Red
White
Black
Red and Black
Black and White
Red and White
Resistance should be 600 ohms or less.
Measure resistance between:
Motor shaft should
turn easily.
