USER INTERFACE
EN
INTELECT
®
RPW 2 USER MANUAL
Each screen contains the following areas:
Menu Bar
Located at the top of each screen and lists the current screen name.
Main area
Located under the menu bar, this area displays icons unique to the current screen.
. Menu Bar
. Main Area
. Channel Bar
Go to Home Screen Go to Previous Screen
USB
Settings
Current Screen Name
