18
RO05
Figure 26: Example of the result of a measurement of an
reverse phase sequence.
Foreward sequence is displayed
The phase assumed to be L1 leads the phase
assumed to be L2, which itself leads the phase
assumed to be L3.
RO07
Figure 27: Example of the result of a measurement of a
forward phase sequence.
5.5.4 Error messages
If the measurement is impossible, a warning
message is displayed.
Waiting time exceeded
A maximum time of 10 seconds is allowed between
steps 1 and 2.
RO06
Figure 28: Waiting time exceeded.
Frequency out of bounds or signal too weak
RO08
Figure 29: Frequency out of bounds or signal too weak.
