Assembly
Assembly
As indicated, mount the needle roller bearing of input
shaft with special deift punch and be sure it is pressed
onto due position.
Apply grease onto the lips of oil seal and press the oil
seal onto its due position with special tool.
Dismantlement and assembly of oil seal of input shaft
Dismantlement: When dismantling the oil seal of input
shaft, it is not necessary to disassemble the transmission
assy.
Dismantlement and assembly of cone bearing
They are intermediate bearings, and meant to the
differential bearings that are respectively installed on the
clutch housing and transmission housing. When
mounting cone bearing, pay attention not to confuse, esp.
never replace the outer and inner loops matched for the
two same differential bearings. When changing the cone
bearing, readjust the mounting positions of relevant
shafts/bearings.
Dismantle the oil seal of input shaft with special tool as
indicated in figure.
Special tool
Special tool
Special tool
Special tool
22
