Maintenance Manual for Chery·Windcloud Marelli EFI System
No
Diagnosis
Instruction
Failure: improper system voltage signal
Step Operation Result Solution
1
Connect scanner and commutator, and then turn
ignition switch to “OFF”.
Go to next step
Yes Go to next step
2
Check battery voltage with a multimeter to see if it
is around 12V.
No
Replace
battery
Yes
Repair or
replace wire
harness
3
Check respectively the connections between Pin 44,
45, 63 of ECU and Pin 87 of main relay to see if
open circuit or short circuit to ground occurs.
No Go to next step
Yes Go to next step
4
Start engine, check charging voltage of generator at
different engine speeds to see if it maintains within
9-16V.
No
Replace
generator
Yes
Diagnosis
Instruction
5
Check ground point of engine wire harness to see if
it is normal.
No
Repair or
replace wire
harness
Failure: too low system voltage
Step Operation Result Solution
1
Connect scanner and commutator, and then turn
ignition switch to “OFF”.
Go to next step
Yes Go to next step
2
Check battery voltage with a multimeter to see if it
is around 12V.
No
Replace
battery
Yes
Repair or
replace wire
harness
3
Check respectively the connections between Pin 14,
15, 29 of ECU and supply wire to see if the
resistances are too high.
No Go to next step
Yes Go to next step
4
Start engine, check charging voltage of generator at
different engine speeds to see if it maintains within
9-16V.
No
Replace
generator
5
Check ground point of engine wire harness to see if
it is in good condition.
Yes
Diagnosis
Instruction
31
