CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
Assembly procedure:
Put the return spring on the cam;
Install the cam and fix with the
pawl spring;
The tightening torque for the
pawl spring’s positioning bolt:
3.Install the air throttle cable;
4. late
Dis cedure:
ry’s negative
2. utral start
switch’s wiring harness.
1.
2.
10Nm
Install the control valve p
assembly
5. Install the oil pan and its
gasket;
6. Lower the vehicle.
Neutral start switch
assembly pro
1. Remove the batte
terminal;
Remove the ne
47
