CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
T
49
he control mechanism’s
ectromagnectic interlock
isassembly procedure:
Remove the battery’s
negative terminal;
Remove the central control
panel;
Remove the electromagnetic
interlock.
ssembly procedure:
Install the electromagnetic
interlock and fix it with a
bolt;
Tightening torque: 8Nm
Connect the electromagnetic
interlock’s electric terminal;
battery’s
Oil feed pipe
isassembly procedure:
Remove the battery;
2. L
ug to
.
el
D
1.
2.
3. Remove the electromagnetic
interlock’s electric terminal;
4.
A
1.
2.
3. Install the central control
panel;
4. Connect the
negative terminal.
D
1.
ift the vehicle;
pl3. Loosen the oil drain
drain the oil;
4. Loosen the fixing bolt on upper
part of the oil feed pipe
