CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
Pa
117
rking mechanism
K
K
D edure:
Remove the automatic
transmission assembly from the
vehicle;
Remove the oil pan from the
automatic transmission;
Remove the control valve plate
assembly;
Remove the side cover and
5.
Take out parking connecting
rod and parking cam;
7
Special tool:
A-000-187 oil sealing remover
A-000-287 oil sealing assembler
isassembly proc
1.
2.
3.
4.
gasket;
Remove the lock plate spring
on the brake disk.
6.
. Remove the shift shaft’s dowel
pin;
