CHERY AUTOMOBILE CO., LTD Automatic Transmission Fault Diagnosis Manual
12. Take off the oil circuit board
together with the top baffle
from the middle valve plate.
Turn over the oil circuit board
and top baffle. Put them on the
worktable.
. Take out the vent valve ball,
lock piece and throttle metal
tab from the middle valve
plate;
13
14. Separate the top baffle from the
oil circuit board;
127
