Chery A11 2003 User Manual

CIRCUIT Central Electrical Box Connector Position
Central Electrical Box Connector, Pin and Function
Connector Connector Pin Function
Circuit
No.
A
01.Sunroof, Cab Freight Calculator (+15)
02.ECUA/C Signal Input
03.——
04.Luggage Compartment Lamp, Radio, Ceiling Lamp
05.——
06.——
07.——
08.——
09.Rear Window Preheat Switch, Rear Mirror Defrost
Switch
10.——
11.Lamp Switch Illumination, ABS Diagnostic Power
(+15)
12.——
13.Combination Instrument Power Positive (+30)
14. Brake Switch
—
138
—
247
—
—
—
—
134
—
132
—
114
192
B
01.——
02.——
03.——
04.A/C Relay, Blower, Interior Circulate Solenoid
Switch
—
—
—
51
C
01.Horn Switch
02.Fog Lamp Relay (Positive)
03.Fog Lamp Switch
04.Horn Relay Signal (30)
05.Dual Pitch Horn
06.Wiper Motor (Positive)
07.Panel Indicator, Switch Illumination Light, Light Switch
Variable Resistor
08.Back Light Switch
09.——
10.——
11.——
12.Fog Lamp Relay (Positive)
13.——
14.——
15.Thermo Switch, A/C High Pressure Switch
16.Central Electrical Box Power Positive (+30)
142
219
220
140
141
154
209
83
152
—
—
215
—
—
47
6
—
2 —
