CIRCUIT Central Electrical Box Connector Position
CIRCUIT__Central Electrical Box Connector, Pin and Function
Connector Connector Pin Function
Circuit
No.
C
17.——
18.Wiper Intermittent Relay
19.Lincense Plate Lamp
20.Mileage Gauge Sensor
—
149
210
81
D
01.——
02.Cigar Lighter
03.Turn Light Switch, Headlight Adjustment
Switch
04.——
05.Combination Instrument Positive (+15)
06.Sunroof, Cab Freight Calculator (+30)
07.Ground
08.——
09.Rear View Mirror、Lifter Module、 Position Select
Box (+15)
10.Ignition Switch (+15)
11.Central Locking Controller, Glass Lifter Module
(+30)
12.Ignition Switch, Wiper Switch (+15)
13.Central Electrical Box Power Positive (+30)
14.——
15.——
16.——
—
129
175
—
116
—
53
—
272
14
260
8
10
—
—
248
E
01.——
02.——
03.——
04.A/C Compressor Magnetic Clutch
05.——
06.——
07.——
08.Central Electrical Power Positive (+30)
09.Ignition Switch (+15)
10.Lamp Switch
11.——
12.Horn Relay
13.——
14.——
—
—
—
137
—
—
—
5
9
207
—
139
—
—
—
3 —
