SQR7080 Service Manual 372 Engine Mechanical System
Chery Automobile Co., Ltd
Remove the timing belt.
[Caution] It is absolutely not allowed to use screw
driver or some other sharp-edged tools to remove the
belt.
Attention: Pay attention to the following points while
using timing belt:
- Don’t bend the belt even at a small angle,
otherwise it will result in rope fracture inside the
belt.
- - Service life of belt is short, don’t pollute the belt
with grease and water.
- You have no choice but rotate the engine
clockwise after installing the belt.
2.7 Remove the crankshaft timing gear
