Mini Fuses Usage
53
Traction
Power Inverter
Module – Run/Crank
54
Run/Crank for Air
Conditioning Control
Module/Instrument
Cluster/Passenger
Airbag Display/
Accessory Power
Module
J‐Case
Fuses
Usage
16 Empty
18 Empty
19
Power
Window – Front
20 Empty
21
Antilock Brake
System Electronic
Control Unit
J‐Case
Fuses
Usage
23 Charge Port Door
27 Empty
28 Empty
29 Empty
30
Antilock Brake
System Motor
42 Cooling Fan – Right
43 Front Wipers
44 Charger
45 Empty
48 Cooling Fan – Left
Mini Relays Usage
3 Powertrain
4
Rear Defog (Lower
Grid)/Heated Mirrors
7 Empty
Mini Relays Usage
9 Empty
11 Empty
12 Empty
13 Empty
14 Run/Crank
Micro
Relays
Usage
1 Empty
2 Empty
6 Empty
8 Empty
10 Empty
Ultra Micro
Relays
Usage
5 Charge Port Door
