Mini Fuses Usage
15
Traction Power
Inverter Module
and Transmission
Control
Module – Battery
17
Engine Control
Module – Battery
22
Left High‐Beam
Headlamp
24 Empty
25 Empty
26 Empty
31
Rechargeable
Energy Storage
System (High
Voltage Battery)
Coolant Pump
32
Sensing Diagnostic
Module – Run/Crank
Mini Fuses Usage
33
Run/Crank for Fuel
System Control
Module/Vehicle
Integration Control
Module
34
Vehicle
Integration Control
Module – Battery
35
Power Electronics
Coolant Pump
36 Empty
37
Cabin Heater
Control Module
38 Empty
39
Rechargeable
Energy Storage
System (High
Voltage Battery)
Control Module
Mini Fuses Usage
40
Front Windshield
Washer
41
Right High‐Beam
Headlamp
46 Empty
47 Empty
49 Empty
50
Rear Vision
Camera – Run/
Crank (If Equipped)
51
Run/Crank for
ABS/Rechargeable
Energy Storage
System (High
Voltage Battery)/
Charger
52
Engine
Control Module/
Transmission
Control
Module – Run/Crank
