Chino DB670 User Manual

[DB600] General Instruction Manual
- 8 -
 DB650
DB6④⑤⑥⑦⑧⑨⑩⑪⑫0⑭
5: 48 x 96 size
0: PID control
Z: Z control
1: ON-OFF pulse output type
2: ON-OFF servo output type
3: Current output type
5: SSR drive pulse output type
6: Voltage output type
0: None
1: ON-OFF pulse output type *1
3: Current output type *1
5: SSR drive pulse output type *1
6: Voltage output type *1
0: None
A: RS422A + 5 External signal input points [DI 1 to 5]
S: RS485 + 5 External signal input points [DI 1 to 5]
B: RS422A + 5 Status event output points (open
corrector output) [EV 5 to 9]
C: RS485 + 5 Status event output points (open
corrector output) [EV 5 to 9]
D: 5 External signal input points [DI 1 to 5]
E: 5 Status event output points (open corrector
output) [EV 5 to 9]
0: None
1: 4 to 20mA
2: 0 to 1 V
3: 0 to 10V
4: 4 to 20mA + 2 Alam event output points
(mechanical relay output) [EV 3, 4]
*1
5: 0 to 1V + 2 Alam event output points (mechanical
relay output) [EV 3, 4]
*1
6: 0 to 10V + 2 Alarm event output points
(mechanical relay output) [EV 3, 4]
*1
7: 2 Alarm event output points (mechanical relay
output) [EV 3, 4]
*1
0: None
5: 4 to 20mA
6: 0 to 1V
7: 0 to 10 V
8: 4 to 20mA + 2 External signal input points [DI6, 7]
*2
9: 0 to 1V + 2 External signal input points [DI6, 7]
*2
A: 0 to 10V + 2 External signal input points [DI6, 7]
*2
B: 2 External signal input points [DI6, 7]
*2
- : None
P: Available
④Size
⑤Control algorithm
⑥Control output 1
⑦Control output 2 (Option)
⑧Communications interface +5 External signal
input points/ 5 Status event output points
(Option)
⑨Transmission signal output + 2 Alarm event
output points (Option)
⑩Remote signal input + 2 External signal input
points (Option)
⑪Programming function (Option)
