 Input type, measuring range and accuracy rating
Input type
Measuring range
Measured accuracy
Thermocouple
B
0.0 to 1820.0
±0.1% of FS±1digit
For below 0°C,
±0.2% of FS±1digit
Below 400°C
：
Out of specification
400 to 800°C
：
±0.2%FS ±1digit
R
0.0 to 1760.0
Below 400°C
：
±0.2%FS ±1digit
S
0.0 to 1760.0
N
0.0 to 1300.0
K1
-200.0 to 1370.0
K2
-200.0 to 500.0
E
-200.0 to 900.0
J
-200.0 to 1200.0
T
-200.0 to 400.0
U
-200.0 to 400.0
L
-200.0 to 900.0
W-WRe5-26
0.0 to 2310.0
W-WRe26
0.0 to 2310.0
Below 400°C
：
±0.4% FS ±1digit
Platinel II
0.0 to 1390.0
PtRh40-20
0.0 to 1880.0
±0.3% of FS±1digit
Below 400°C
：
±1.5% FS ±1digit
400 to 800°C
：
±0.8%FS ±1digit
Au-Pt
0.0 to 1000.0
±0.1% of FS±1digit
Resistance
thermometer
Pt100Ohm1
-200.0 to 850.0
±0.1% of FS±1digit
Pt100Ohm2
-200.0 to 200.0
JPt100Ohm1
-200.0 to 649.0
JPt100Ohm2
-200.0 to 200.0
Pt50Ohm
-200.0 to 649.0
DC voltage
20mV
-20.00 to 20.00
±0.1% of FS±1digit
100mV
-100.0 to 100.0
5V
-5.000 to 5.000
10V
-10.000 to 10.000
* Accuracy indicates the performance under reference operating condition.
* For thermocouple, the reference junction compensation accuracy is added to the above measured
accuracy.
 Applicable standard
Input type
Applicable standard
Thermocouple
B, R, S, N, K, E, J, T
IEC584(1977,1982), JIS C 1602-1995, JIS C 1605-1995
U, L
DIN43710-1985
W-WRe26, Platinel II,
PtRh40-PtRh20, Au/Pt
ASTM E1751
WRe5-WRe26
ASTM E988
Resistance
thermometer
Pt100
IEC751(1995), JIS C 1604-1997
JPt100
JIS C 1604-1981, JIS C 1606-1986
Pt50
JIS C 1604-1981
