[DB600] General Instruction Manual MODE 2
- 74 -
□□□□
▲ SEL ↑ ↓ ▼ SEL
Pattern repeat
Set this to operate a whole pattern (from the step No. 00 to the end step No.)
repeatedly. (Example 1)
   
"
□□□□
"
No pattern repeat
"
□□□□
"
to
"
□
"
Pattern repeat count
Use the [

] or [

] and [ENT] keys to set the pattern repeat.
Use the [>] key to move the cursor to the right digit.
When a pattern link has been set, a whole pattern including the pattern link will be
repeated. (Example 2)
When an infinite loop has been created in a pattern link, the pattern repeat will be
disabled. (Example 3)
(Example 1) When "3" is set, an initial program operation + repeated operation for
three times, i.e., the operation will be executed four times.
(Example 2) Operation with pattern 1 (linked to pattern 2), pattern 2 (no pattern
link), pattern repeat 2
[RUN] -> pattern 1 -> pattern 2 -> pattern 1 -> pattern 2 -> pattern 1 -> pattern 2 ->
[END]
(0) (once) (twice)
(Example 3) Operation with pattern 1 (linked to pattern 2), pattern 2 (linked to
pattern 1), pattern repeat 0 (pattern link is not required in this case)
[RUN] -> pattern 1 -> pattern 2 -> pattern 1 -> pattern 2 -> pattern 1 -> pattern 2 -> ...
(0) (once) (twice) (infinitely)
□
▲ SEL ↑ ↓ ▼ SEL
Operation screen time
display
Selects the type for PV/step time progress display on the operation screen.
"
□
"
Step elapsed time
" "
Step remaining time
Use the [

] or [

] and [ENT] keys to set the time display on the operation screen.
□□
▲ SEL ↑ ↓ ▼ SEL
Pattern clear
Clears (initializes) the pattern information (SV in step, time, and program operation
execution No.).
"
□□
"
No pattern clear
Pattern clear completed
"
□
"
Initialize pattern No. 1
"
□
"
Initialize pattern No. 2
"
□
"
Initialize pattern No. 3
"
□
"
Initialize pattern No. 4
"
□□
"
Initialize all patterns
Use the [

] or [

] and [ENT] keys to set the pattern clear.
At the end of pattern clear, " " will be displayed.
The following parameters in a pattern will be initialized.
Step
Parameter type
Default
Start step
Number of steps
0
Program operation PV start
SV (SV start)
Start SV
0.0
Middle step
SV for program operation
0.0
Step time
0:00
Execution No. selection for
program operation
Execution No. 1 (step No. 1)
Execution No. 0 (other than
step No. 1)
End step
Output 1 at END
CONTROL
Output 2 at END
CONTROL
Linked pattern No.
OFF
Pattern settings (program/constant value operation switch, program operation time
unit, SV in RESET, pattern repeat and operation screen time display) will not be
initialized.
□
□□
▲ SEL ↑ ↓ ▼ SEL
Pattern copy
Copies the pattern information (SV in step, time, and execution No.).
"
□□
"
No pattern copy (pattern copy ended)
"
XX YY
"
Copy the pattern No. XX (source) to the pattern No. YY
(destination).
Use the [

] or [

] and [ENT] keys to set the pattern copy.
At the end of pattern copy, "□□ " will be displayed.
