Chino DB670 User Manual

[DB600] General Instruction Manual MODE 2
- 75 -
□
▲ SEL ↑ ↓ ▼ SEL
Start step setting
Pattern No./
Start step No.
Displays or selects an arbitrary pattern No./step No.
"
□
"
to
"
□
"
Select a pattern No. and step No. of the parameter group
displayed when the [SEL] key is pressed.
Use the [

] or [

] key to select an arbitrary pattern No./step No. screen.
Pressing the [

] key displays the pattern setting screen or pattern No./end step No.
screen.
Pressing the [

] key displays the pattern No./middle step No. or pattern No./end step
No. screen.
No parameter is set by the [ENT] key.
Step No. is displayed up to the number of steps + 1.
□
□□□□
▲ SEL ↑ ↓ ▼ SEL
Number of steps
Sets the number of steps within a program pattern.
The number of steps can be set for each pattern.
"
１１１１
"
No step
* No step exists in a program pattern. Operation cannot be
started.
"
１１１１
"
to
"
１１１
"
Sets the number of steps in a program pattern.
Use the [

], [

] and [ENT] keys to set the number of steps.
Use the [>] key to move the cursor to the right digit.
The SV for program operation, step time, and execution No. selection at program
operation will not be initialized even when the number of steps is set/changed.
□□□
▲ SEL ↑ ↓ ▼ SEL
Program operation
PV start
Sets the start method for program operation.
"
１１１
"
"Start SV (MODE2)" is used immediately after pattern start.
"
１１１
"
Program pattern is progressed to the PV immediately after
pattern start (PV start) before starting operation. If the SV that
matches the PV cannot be found within the pattern, SV start is
used to start operation.
Use the [

], [

] and [ENT] keys to set the program operation PV start.
When PV start is set on a pattern immediately after pattern repeat or pattern link, a
repeated and linked pattern will be started with PV start.
SV search at PV start will not be performed for a linked pattern.
□□□
▲ SEL ↑ ↓ ▼ SEL
Start SV
Sets an SV immediately after starting program operation. Start SV will be disabled
when PV start is selected for operation start.
" "
to
" "
Target value immediately after operation start
* The setting range is limited by "SV limiter (MODE5)".
Use the [

], [

] and [ENT] keys to set the Start SV.
Use the [>] key to move the cursor to the right digit.
□
▲ SEL ↑ ↓ ▼ SEL
Middle step setting
Pattern No./
middle step No.
Displays or selects an arbitrary pattern No./step No.
"
□
"
to
"
□
"
Select a pattern No. and step No. of the parameter group
displayed when the [SEL] key is pressed.
Use the [

] or [

] key to select an arbitrary pattern No./step No. screen.
Pressing the [

] key displays the pattern No./start step No. screen.
Pressing the [

] key displays the pattern No./middle step No. or pattern No./end step
No. screen.
No parameter is set by the [ENT] key.
Step No. is displayed up to the number of steps + 1.
□□□
□□□
▲ SEL ↑ ↓ ▼ SEL
SV for program
operation
Sets a step SV.
" "
to
" "
Attainment target value of step
* The setting range is limited by "SV limiter (MODE5)".
Use the [

], [

] and [ENT] keys to set the SV for program operation.
Use the [>] key to move the cursor to the right digit.
