Spring Commissioning - (Continued)

4-6 4-6

Boat Systems (Continued)

_______ All 12 Volt receptacles tested

_______All battery cables secure - POSITIVE & GROUND

_______ Battery switches - ON & OFF - check voltage at the gauge panel

_______ Check all thru-hull fittings immediately after launch

_______ Inspect the bilge area for leaks

_______Check all seacocks for leaks

_______Check engine oil level capacity for four stroke engines

_______ Prime engines with primer bulbs

_______ Neutral safety switch is functional

_______ Electric starters operational

_______ Check throttle operation, friction adjustment, neutral and cruising positions

_______ Before leaving the dock check that bilge pump outlets are not pumping water

_______ Proper shift cable adjustment/Operation (Forward-Neutral-Reverse)

_______ Check power trim and tilt operation while underway

_______ Verify speedometer operation

_______ Proper instrument operation and displays, Volts, Temperature, and RPM

_______ check engine shut down procedure (KILL SWITCH AND KEY SWITCH)

_______ Check steering - correct turns port to starboard and record wheel play in inches

_______ Steering: Record wheel play in inches

_______ Steering: Tilt helm functioning properly

_______ Steering: Check all seams and fittings for leaking

NOTES:____________________________________________________________________________

___________________________________________________________________________________

Storage And Commissioning

Chris-Craft 32 Launch (RJ) User Manual
