Appendix G
25
1/2”
134
PORT SIDE THRU HULL FITTINGS
Head Blower
Outlet
2-3/4” Hole
119
”
27
1/2”
94-
83
”
79
”
38
”
9-
(Optional)
Macerator
Pump
Thru-Hull
2” Dia.
48
Transducer
Thru-Hull
2-3/8” Dia.
54
Bottom Thru-hull Fittings are drilled from inside the
Keel
Figure G-1. RJ Port Side Thru Hull Fittings
High Water
Bilge Pump
1-3/8” Hole
Optional
Techma
Flush Vent
1-3/8” Hole
Water Vent
1-3/8” Hole
Sink Drain
7/8” Hole
G-2 G-2
