G-33 G-33
Figure G-37 Docking Lights Switch Panel
Appendix G
A/C SEACOCK
670 - 8 GREEN
#10 RING
ZINK
600 - 8 GREEN
640 - 8 GREEN
1/2" RING
GENERATOR
SEACOCK
632 - 8 GREEN
#10 RING
GENERATOR
SEASTRAINER
635 - 8 GREEN
#10 RING
GENERATOR
630 - 8 GREEN
3/8" RING
BONDING BU SS
ALL WIRES ARE GREEN
8 GA: 600, 601, 630, 632,
635, 670
DRAIN PLUG
640 - 8 GREEN
#10 RING
028-2492
65"
24"
55"
24"
12"
24"
7"
18"
8"
GROUND JUMP
601 - 8 GREEN
1/4" RING
028-2492
BONDING BUSS
ALL WIRES ARE GREEN
8 GA: 600, 601, 630, 632,
635, 670
NOTE: This wire harness applies
to the RJ Model only. The RK
has this harness incorporated
into the main hull harness.
GROUND JUMP
601-8 GREEN
1/4” RING
GENERATOR
SEACOCK
632 - 8 GREEN
#10 RING
AIR CONDITIONER
SEACOCK
670 - 8 GREEN
#10 RING
DRAIN PLUG
640 - 8 GREEN
#10 RING
GENERATOR
SEA STRAINER
635 - 8 GREEN
#10 RING
ZINC
600 - 8 GREEN
640 - 8 GREEN
1/2” RING
GENERATOR
630 - 8 GREEN
3-8” RING
8”
65”
24”
24”
7”
12”
55”
18”
NON-SERVICEABLE UNIT.
REMOVE AND REPLACE THE UNIT. IT IS NOT SERVICEABLE.
Step 1: Fasten the light to the hull with #6 x 3/4” stainless steel pan head
screws provided by the vendor in the light assembly. Caulking is not
necessary.
Step 2: Place the rear tab of the cover into the notch at the back of the light.
Step 3: Slide the cover forward and rotate it onto the light.
Step 4: Hold the cover to the light and tighten the final three screws.
Figure G-38
Replacing The Docking Lights Figure G-39 Starboard Light
Figure G-40
Port Light
