Freeze-dryer Alpha 1-4 LSCplus
Freeze-dryer Alpha 2-4 LSCplus
6 Operation
Version 01/2011, Rev. 2.3 of 03/07/2017 • sb
51 / 131
Translation of the original operating manual
Change scale unit (2)
This dialog box is used to change the unit of measurement for the
temperature and vacuum.
Fig. 36: Dialog box "Change scale unit"
Freeze-drying process (3)
NOTE
This function depends on the unit type and is not available for all types of
freeze-dryers.
Prior to the start of the process, the correct process must be selected. The
following processes are available:
•  Single-chamber method (inside): drying inside the ice condenser
chamber
•  Double-chamber method (outside): drying outside the ice condenser
chamber
• Double chamber method LyoCube (outside): drying outside the ice
condenser chamber, but with the CHRIST LyoCube (a rectangular
drying chamber that can be loaded from the front)
Fig. 37: Dialog box "Freeze-drying processes"
