HIPOT Tester 19071/19072/19073 User’s Manual
2-6
(10) RS-232 Interface Card:
This socket is for RS-232 interface which provided by the tester, it uses binary code
transmission mode. Its command format is the same as RS-485 interface.
(11) RS-485 Slot
This slot supports two sockets of RJ-45, which provides multi-link function for the link
test model of 19073 + RS485.
2.3 Operation
[Standby Menu]: The screen appears as below after powered on.
STEP 1/ 1 AC
LOW :OFF
PROGRAM
0.000KV
ARC :OFF
RAMP:OFF
PRESET
0.500mA
FALL:OFF
MENU
3.0s
MORE..
STANDBY RMT LOCK OFST ERR
2.3.1 Memory Process
■ How to enter the Memory Process menu
(1) In [Standby Menu], press the Function Key [MENU], it appears:
LAST
1.MEMORY
2.SYSTEM
DOWN
3.OPTION
4.CALIBRATION
SELECT
5.KEY LOCK
EXIT
SELECT FUNC.
RMT
LOCK
OFST
ERR
(2) Use Function Key [F1] and [F2] to move the highlight to “MEMORY”, and press
Function Key [F3] to enter memory process menu as below:
STORE
1. (0 STEPS)
2. (0 STEPS)
RECALL
3. (0 STEPS)
4. (0 STEPS)
DELETE
5. (0 STEPS)
RETURN
SELECT FUNC.
RMT
LOCK
OFST
ERR
(3) At this time select execution action by pressed Function Key [F1], [F2] or [F3], it
appears:
