HIPOT Tester 19071/19072/19073 User’s Manual
5-12
Descriptions of example
The setting meanings of HEX inputs are as the following:
0xAB = Header
0x01 = Destination Address
0x70 = Source Address
0x01 = Data Field Length
0xA5 = Data Field Length
0xE9 = Checksum
The reading meanings of returning HEX code are as the following:
0xAB = Header
0x70 = Destination Address
0x01 = Source Address
0x07 = Data Field Length
0xA5 = Command Code
0x3C = ACV Frequency 60Hz (Return Data)
0x01 = Software AGC ON (Return Data)
0x00 = WV Auto Range OFF (Return Data)
0x01 = IR Auto Range ON (Return Data)
0x01 = Ground Fault Interrupt (GFI) ON
0x00 = Fail Restart OFF (Return Data)
0x01 = Screen ON
0xA2 = Checksum
Store Memory
Description: It saves the parameters of various steps and Preset to the internal
memory.
Command code: 0x26
Parameter: Serial number of memory + Name of memory. The length of serial
number of memory is 1 character. The range is 1 ~ 60, the name
length of the memory is 0 ~ 10 character.
Return data: Reply Message
Example: Master (0x70): 0xAB 0x01 0x70 0x08 0x26 0x01 0x43 0x48 0x52 0x4F
0x4D 0x41 0xA6
Slave (0x01): 0xAB 0x70 0x01 0x02 0x7F 0x00 0x0E
Remark: When the name of memory is lowercase character, it will change to
uppercase character automatically.
Descriptions of example
The setting meanings of HEX inputs are as the following:
0xAB = Header
0x01 = Destination Address
0x70 = Source Address
0x08 = Data Field Length (Length of memory name is 6)
0x26 = Command Code
0x01 = Memory S/N
0x43 0x48 0x52 0x4F 0x4D 0x41 = ”CHROMA” Memory Name
(Command Parameter)
0xA6 = Checksum
The reading meanings of returning HEX code are as the following:
0xAB = Header
