HIPOT Tester 19071/19072/19073 User’s Manual
5-14
The reading meanings of returning HEX code are as the following:
0xAB = Header
0x70 = Destination Address
0x01 = Source Address
0x02 = Data Field Length
0x7F = Reply Message Command Code
0x00 = Reply Message Return Data
0x0E = Checksum
System Setting
Description: It sets the system parameter.
Command code: 0x29
Parameter: 4 bytes
Name
Size
(byte)
Unit
Range
Description
Contrast
1
-
1~15
Buzzer Volume
1
-
0/1/2/3
0:OFF, 1:Low, 2:Medium, 3:High
EN50191
1
-
0/1
0:OFF, 1:ON (AC maximum is 3mA)
DC 50V AGC
1
-
0/1
0:OFF, 1:ON
Pass On
1
100mS
0 ∼ 100
0:OFF
END OF STEP
1
-
0/1
0:OFF, 1:ON
EOT 1 - 0/1
0:END OF TEST,
1:END OF TIMER
Return data: Reply Message
Example: Master (0x70): 0xAB 0x01 0x70 0x08 0x29 0x0A 0x03 0x00 0x00 0x00
0x00 0x01 0x50
Slave (0x01): 0xAB 0x70 0x01 0x02 0x7F 0x00 0x0E
Descriptions of example
The setting meanings of HEX inputs are as the following:
0xAB = Header
0x01 = Destination Address
0x70 = Source Address
0x08 = Data Field Length
0x29 = Command Code
0x0A = Contrast 10 (Command Parameter)
0x03 = Buzzer Volume High (Command Parameter)
0x00 = EN50191 OFF (Command Parameter)
0x00 = DC 50V AGC OFF (Command Parameter)
0x00 = PASS ON OFF (Command Parameter)
0x00 = END OF STEP OFF (Command Parameter)
0x01 = END OF TIMER (Command Parameter)
0x50 = Checksum
The reading meanings of returning HEX code are as the following:
0xAB = Header
0x70 = Destination Address
0x01 = Source Address
0x02 = Data Field Length
0x7F = Reply Message Command Code
0x00 = Reply Message Return Data
