Chroma 19073 - Rear Panel Overview

Operation and Setting
2-3
2.2 Rear Panel
The rear panel is divided into several areas. This section describes the function of each area.
The standard rear panel of 19071/19072/19073:
(1) (7)
(2) (8) (9) (3) (5) (4) (6)
The rear panel of link test model of 19073 + RS232 is shown as below:
(10)
